MSI Z690-A WIFI DDR4 Desktop Motherboard - Intel Chipset - Socket LGA-1700 - Intel Optane Memory Ready - ATX

$239.99
None availableas of 10/13/2026

Ships when available. Free shipping on most items when you spend $100 or more.

Special orders typically ship in 1-12 weeks.

Country of origin

  • Origin: China
Rated excellent by our customers Read our reviews

Secure checkoutISO 9001:2015 and CMMC certifiedFamily owned since 1982

Free shipping on most items when you spend $100 or more.

Real people answer: chat with us, email customerservice@colamco.com, or call 1-800-692-8757, Monday to Friday, 8am to 5pm EST.

Protect this device

Plans are optional and can be left off. Your order is unchanged unless you add one.

Secure checkoutISO 9001:2015 and CMMC certifiedFamily owned since 1982

Free shipping on most items when you spend $100 or more.

Real people answer: chat with us, email customerservice@colamco.com, or call 1-800-692-8757, Monday to Friday, 8am to 5pm EST.

Overview

PRO SERIES

PRO series helps users work smarter by delivering an efficient and productive experience. Featuring stable functionality and high-quality assembly, PRO series motherboards provide not only optimized professional workflows but also less troubleshooting and longevity.

Technical specifications

General Information

Manufacturer MSI
Manufacturer Part Number Z690AWIFDDR4
Manufacturer Website Address http://www.msi.com
Brand Name MSI
Product Series PRO
Product Model Z690-A WIFI DDR4
Product Name PRO Z690-A WIFI DDR4 Desktop Motherboard
Product Type Desktop Motherboard

Processor & Chipset

Chipset Manufacturer Intel
Chipset Model Z690
Total Processor Supported 1
Processor Socket Socket LGA-1700
Processor Generation Supported 12th Gen
Processor Supported Pentium GoldCeleronCore i5Core i7Core i9
Multi GPU Supported CrossFire

Memory

Number of Memory Slots 4
Memory Form Factor DIMMUDIMM
Maximum Memory 128 GB
Memory Technology DDR4 SDRAM
Memory Speed Supported 5200 MHz4800 MHz4000 MHz2133 MHz2666 MHz2933 MHz3200 MHz
Intel Optane Memory Ready Yes

I/O Controller

Controller Type Serial ATA/600
RAID Supported Yes
RAID Levels 01510

Video

Onboard Video CPU Dependent Video

Audio

Audio Channels 7.1

Network & Communication

Bluetooth Yes
2.5Gigabit Ethernet Yes
Wireless LAN Yes
Wireless LAN Standard IEEE 802.11 a/b/g/n/ac/ax

I/O Expansions

Total Number of Expansion Slots 4
Total Number of PCI Express Slots 4
Number of PCI Express x4 Slots 1
Number of PCI Express x16 Slots 3

Interfaces/Ports

Total Number of USB Ports 8
Number of USB 2.0 Ports 4
Number of USB 3.2 Ports 1
Number of USB 3.2 Gen 1 Ports 2
Number of USB 3.2 Gen 2 Type-A Ports 1
HDMI Yes
DisplayPort Yes
Number of Network (RJ-45) Ports 1

Onboard Interfaces

Number of SATA Interfaces 6
Number of M.2 Interfaces 4
Total Number of Onboard USB Ports 9
Number of Onboard USB 2.0 Ports 4
Number of Onboard USB 3.2 Ports 5

Physical Characteristics

Form Factor ATX
Width 12"
Depth 9.6"

Miscellaneous

Country of Origin China

Warranty

Limited Warranty 3 Year
