Eaton 9170+ Rackmount UPS 12 to18 kVA UPS

Part #: 1-645262

Eaton 9170+ Rackmount UPS 12 to18 kVA UPS

Part #: 1-645262 MFG Part #: PW12S12K-PD UPC #: 000003336380
$17,412.00 $10,790.81
Save $6,621.19
SPECIAL ORDER

0 Available

(as of Feb 14, 2026 2:21 AM) Refresh Inventory
OVERSIZED / HEAVY ITEM

This is an oversized / heavy item and requires extra shipping and handling time.

AUTHORIZED DEALER
AUTHORIZED DEALER
AUTHORIZED DEALER

AUTHORIZED DEALER

About the Eaton 9170+ Rackmount UPS 12 to18 kVA UPS

With a scaleable, modular and redundant design, the Powerware 9170+ Rackmount UPS provides advanced backup power and power quality management and offers the highest level of power protection and power quality of any Rackmount UPS power supply in the 3-18 kVA range.

Technical Specifications of the Eaton 9170+ Rackmount UPS 12 to18 kVA UPS

General Information


Manufacturer Eaton Corporation
Manufacturer Part Number PW12S12K-PD
Manufacturer Website Address http://www.eaton.com
Brand Name Eaton
Product Name 9170+ Rackmount UPS 12 to18 kVA UPS
Product Type Online UPS

Technical Information


Plug / Connector Type Hardwired
Receptacle Type NEMA L14-30RNEMA 5-20RNEMA L6-30R
Receptacle Detail 12 x NEMA 5-20R3 x NEMA L6-30R3 x NEMA L14-30R

Power Description


Load Capacity (VA) 12 kVA
Input Voltage 110 V AC220 V AC
Output Voltage 120 V AC208 V AC240 V AC
Input Frequency 60 Hz
Output Frequency 60 Hz
Waveform Type Sine Wave

Management


Alarm Low BatteryHigh BatteryLow AC OutputHigh AC OutputHigh AC InputOutput OverloadOverload ShutdownHigh Heatsink TemperatureEmergency Power OffModule FailureExcessive TransferPrecharge FailureIncompatible ModuleFan FailureLow RuntimeCheck MemoryCheck Battery Open CellCheck Battery Weak BatteryLow Redundancy Insufficient BatteryLow Redundancy Insufficient ModuleCheck BatteryPhase Error
Bypass Switch Automatic
Emergency Power OFF Yes

Controls/Indicators


Status Indicators
  • Battery Test Failed

Interfaces/Ports


Modular Slots 2 x Communications Slot

Battery Information


Battery Characteristics Maintenance-free
Battery Chemistry Lead Acid
Backup / Run Time (Full Load) 8 Minute
Backup / Run Time (Half Load) 24 Minute
Typical Battery Recharge Time 4 Hour

Environmental Conditions


Maximum Operating Temperature 104°F (40°C)
Sound Emission (A-Weighted) 50 dB(A)

Miscellaneous


Additional Information
  • Eliminates single point-of-failure with N+X power and logic redundancy
  • Grows with changing IT environments by incorporating scalable design of 3 kVA power modules and batteries
Certifications & Standards
  • UL
  • CUL
  • FCC class A
  • IEEE/ANSI C62.41
Country of Origin United States

Warranty


Limited Warranty 2 Year
