APC Smart-UPS SRT 8000VA 208V

Part #: 1-998263

APC Smart-UPS SRT 8000VA 208V

Part #: 1-998263 MFG Part #: SRT8KXLT UPC #: 731304292791
$14,465.00 $9,251.72
Save $5,213.28
SPECIAL ORDER

0 Available

(as of Jun 27, 2026 2:27 AM) Refresh Inventory
OVERSIZED / HEAVY ITEM

This is an oversized / heavy item and requires extra shipping and handling time.

AUTHORIZED DEALER
AUTHORIZED DEALER
AUTHORIZED DEALER

AUTHORIZED DEALER

Protect your investment ()

About the APC Smart-UPS On-Line

View User Manual
This APC Smart-UPS is designed for IT professionals or network administrators to maintain business uptime and continuity. This 8kVA on-line tower UPS provides pure sine wave power and extended runtime to support critical electronics during power disruptions. It comes with hard wire 3-wire (2P+E) input, 4x NEMA L6-20R and 2x NEMA L6-30R outlets. The UPS has an embedded Network Management Card for UPS network-based monitoring and management. The UPS comes with PowerChute Network Shutdown that provides graceful shutdown of physical servers, virtual machines, and HCI clusters. It has an additional SmartSlot for optional accessory card such as Dry Contact I/O card. The UPS can connect to EcoStruxure IT or third-party centralized management platforms. The UPS has a 3-year warranty, and the built-in lead-acid battery has a 2-year warranty. The UPS is compatible with SRTRK2 (4-post) and SRTRK3 (2-post) rail kits sold separately.

More from the ManufacturerThis APC Smart-UPS is designed for IT professionals or network administrators to maintain business uptime and continuity. This 8kVA on-line tower UPS provides pure sine wave power and extended runtime to support critical electronics during power disruptions. It comes with hard wire 3-wire (2P+E) input, 4x NEMA L6-20R and 2x NEMA L6-30R outlets. The UPS has an embedded Network Management Card for UPS network-based monitoring and management. The UPS comes with PowerChute Network Shutdown that provides graceful shutdown of physical servers, virtual machines, and HCI clusters. It has an additional SmartSlot for optional accessory card such as Dry Contact I/O card. The UPS can connect to EcoStruxure IT or third-party centralized management platforms. The UPS has a 3-year warranty, and the built-in lead-acid battery has a 2-year warranty. The UPS is compatible with SRTRK2 (4-post) and SRTRK3 (2-post) rail kits sold separately.

More from the Manufacturer

Technical Specifications of the APC Smart-UPS On-Line

General Information


Manufacturer Schneider Electric SA
Manufacturer Part Number SRT8KXLT
Manufacturer Website Address http://www.schneider-electric.com
Brand Name APC
Product Line Smart-UPS On-Line
Product Name Smart-UPS SRT 8000VA 208V
Packaged Quantity 1 Each
Product Type Double Conversion Online UPS

Technical Information


Receptacle Type NEMA L6-20RNEMA L6-30R
Receptacle Detail 2 x NEMA L6-30R1 x Hard Wire 3-wire (2PH + G)4 x NEMA L6-20R
Number of Battery & Surge Outlets 6
Phase Single Phase

Power Description


Load Capacity (VA) 8000 VA
Load Capacity (Watt) 8000 W
Input Voltage 208 V AC240 V AC
Output Voltage 240 V AC208 V AC
Waveform Type Sine Wave
Surge Energy Rating 480 J

Battery Information


Battery Chemistry Lead Acid
Backup / Run Time (Full Load) 5 Minute
Typical Battery Recharge Time 1.50 Hour

Physical Characteristics


Color Family Black
Product Color Black
Height 17.01"
Width 10.35"
Depth 28.15"
Form Factor Rack-mountable
Weight (Approximate) 245.99 lb
Mounting Preference No Preference
Mounting Location Front

Miscellaneous


For Country / Region United States
Package Contents
  • Smart-UPS SRT 8000VA 208V
  • CD with software
  • Documentation CD
  • Installation guide
  • Temperature probe
  • USB cable
  • Warranty card
  • Web/SNMP management card
Certifications & Standards ENERGY STAR V2.0 (USA)|FCC part 15 class A|NOM|UL 1778
Energy Star Yes
Green Compliant Yes
Country of Origin Philippines
Product Take Back Program Yes
RoHS Exemption Information https://download.schneider-electric.com/files?p_enDocType=Declaration+of+Conformity+%28Sustainability%29&p_Doc_Ref=SRT8KXLT_ROHS_DECLARATION&p_FileName=SRT8KXLTKIT_ROHS_DECLARATION_US.pdf
REACH Declaration URL https://download.schneider-electric.com/files?p_Doc_Ref=SRT8KXLT_REACH_DECLARATION&p_enDocType=Declaration+of+Conformity+(Sustainability)
EU RoHS Declaration URL https://download.schneider-electric.com/files?p_Doc_Ref=SRT8KXLT_ROHS_DECLARATION&p_enDocType=Declaration+of+Conformity+(Sustainability)
Environmental Profile Availability https://download.schneider-electric.com/files?p_Doc_Ref=ENVPEP1512017EN&p_File_name=ENVPEP1512017_EN.pdf
Energy Star URL https://www.energystar.gov/products/uninterruptible_power_supplies
REACH free of SVHC No
WEEE Statement The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
Environmental Compliance Restriction of Hazardous Substances (RoHS)

Warranty


Limited Warranty 3 Year
Additional Warranty Information UPS: 36 month(s)|Battery: 24 month(s)
